Accession No

2287

Brief Description

moving coil, pointer voltmeter, Weston Elec. Inst. Co., 1923

Origin

Maker

Weston Electric Instrument Co. Ltd

Class

electrical

Earliest Date

1923

Latest Date

1923

Inscription Date

Material

metal (brass, other); plastic (ebonite); paper; wood; glass; hide (leather)

Dimensions

box length 235mm; breadth 180mm; height 104mm

Special Collection

Cavendish collection

Provenance

Transferred from Cavendish Laboratory, University of Cambridge, 1976.

Inscription

‘WESTON
DIRECT
CURRENT
VOLTMETER
21751’ (on dial)
‘WESTON ELECTRICAL INSTRUMENT CO.
MODEL No. 38860
NEWARK, N.J., U.S.A.’ (on metal plate below dial)

Description Notes

Black metal case on wooden base; three ebonite covered terminals, marked ‘+’, ‘3’ and ‘150’; glazed window showing mirror and white dial; hand-printed scale, 0 to 1.5 divisions; circular window below dial showing pivoted coil; metal plate with list of patents on front edge of case; zero adjustment screw on front of base. In wooden carrying case with leather handle; printed paper label glued to bottom of base, dated ‘SEP 12 23’.

Condition: fine; complete.
