Accession No

2386

Brief Description

scale of equal parts in form of a beam compass, by J. Sisson, English, 1740 (c)

Origin

England; London

Maker

Sisson, J.

Class

drawing

Earliest Date

1740

Latest Date

1740

Inscription Date

Material

metal (brass, steel); wood (mahogany)

Dimensions

length 688mm; breadth 37mm; thickness 18mm box length 710mm; breadth 63mm; height 32mm

Special Collection

Provenance

Purchased from D.H. Morgan.

Inscription

‘J. Sisson
London’ (beam)

Description Notes

Brass beam divided 0 - 122 by 1 to 0.1 and 0 - 244 by 1 to 0.1. Vernier reading to 0.01 and 0.02 at a scale of 5 and 10 chains to the inch. (vernier reading to 1 and 2 links). Zero index (badly rusted) with fitting for protracting pin; pin with knurled brass head, rusted into fitting. Sliding index with clamp, slow motion screw vernier and fitting for protracting pin.
Shaped and fitted mahogany case with sliding lid.
