Accession No

3029

Brief Description

combined protractor and range scale, by J. H. Steward, English, 1/2 20th Century

Origin

England; London; 406 Strand

Maker

J. H. Steward

Class

mathematics

Earliest Date

1900

Latest Date

1950

Inscription Date

Material

plastic (celluloid)

Dimensions

length 216mm; width 84mm

Special Collection

Steward collection

Provenance

Collection purchased from member of the Steward family, 1974.

Inscription

‘J. H. STEWARD
LONDON’ (top left corner)

Description Notes

Rectangular sheet of transparent celluloid. Left hand side marked with semicircular protractor, divided [0] - [180˚] and [180˚] - [360˚], numbered by 10˚, subdivided to 1˚; grid in lefthand quadrant marked ‘1/20000 yards’ and divided into 100 squares, numbered 2, 4, 6, 8 on two sides.
Towards right hand edge are a series of ten scales each divided 0 - [6000], numbered by 1000, subdivided to 100. Scale of ‘feet’ marked down right hand edge in 1000s from 9000 to 0.
Scale along bottom edge marked ‘1/20000 yards’, divided 0 - 4500, numbered by 500, subdivided to 100.

Condition good; complete
