Accession No

3030

Brief Description

combined protractor and range scale, by J. H. Steward, English, 1/2 20th Century

Origin

England; London; 406 Strand

Maker

J. H. Steward

Class

mathematics; calculating

Earliest Date

1900

Latest Date

1950

Inscription Date

Material

plastic (celluloid); thread (synthetic)

Dimensions

length 189mm; width 108mm

Special Collection

Steward collection

Provenance

Collection purchased from member of the Steward family, 1974.

Inscription

‘J.H.STEWARD LONDON’ (left edge)

Description Notes

Transparent yellow celluloid rectangle carrying series of 10 scales marked in yards for a ratio of 2 inches to 1 mile and divided 1000 - 6000 numbered by 1000 subdivided to 100 (the uppermost scale is divided [0] - 6000). Near the bottom left corner is attached a thread which moves over a degree scale marked [0] - 90 numbered by 10 subdivided to 1. On the bottom edge is a scale marked in yards for a ratio of 1:20000 divided 0 - 4000 numbered by 1000 subdivided to 50. Scale of ‘feet’ marked down right hand edge in 1000s from 9000 to 0. Grid at lefthand edge marked ‘1/20000 yards’ and divided into 100 squares, numbered 2, 4, 6, 8 on two sides.

Condition good (string broken); complete
