Accession No
3051
Brief Description
simple theodolite, by Huguet, French, early 18th Century
Origin
France; Orleans
Maker
Huguet
Class
surveying
Earliest Date
1700
Latest Date
1825
Inscription Date
Material
metal (brass)
Dimensions
length 122mm; breadth 112mm; height 36mm; compass diameter 79mm box length 140mm; breadth 123mm; thickness 47mm
Special Collection
Steward collection
Provenance
Collection purchased from member of the Steward family, 1974.
Inscription
‘N Huguet Orleans ‘ (on plate)
Description Notes
Simple theodolite, by Huguet, early 18th Century.
Brass circle graduated 0 - 90 - 0˚ twice, clockwise and anticlockwise. Outer scale of a geometric square divided 0 - 50 - 0˚ 4 times. Read by pointer on rotating alidade. Fixed slit sights at 0˚. Alidade and compass rotate in the centre of the circle. Slit sights. Compass rose, 16 point calibrated 0 - 90 - 0˚ twice. Projecting plate from circle, signed and decorated with engraved foliage. 2 rivet holes through plate.
Condition
References
Events
Description
This simple theodolite allows angles to be measured in relation to the fixed sights on the ruler. It has no fitting to secure it on a tripod and was probably used on a plane table to plot angles directly onto the chart being drawn.
10/03/2009
Created by: Dr. Anita McConnell on 10/03/2009
FM:43324
