Accession No
4085.1
Brief Description
control unit for electrocardioscope, by Cambridge Instrument Company Ltd., English, 1959
Origin
England; Cambridge
Maker
Cambridge Instrument Company Ltd.
Class
medical; electrical
Earliest Date
1959
Latest Date
1959
Inscription Date
Material
metal (copper, brass, at least 4 types of white metal); plastic (at least three types)
Dimensions
length 265mm; breadth 200mm; height 195mm
Special Collection
Cambridge Instrument Company Collection
Provenance
Donated by the Cambridge Instrument Company.
Inscription
‘CAMBRIDGE
ELECTROCARDIOSCOPE
Cambridge Instrument
Co. Ltd.,
London and Cambridge
C642344) (top plate)
Description Notes
Control unit for electrocardioscope; this part supplies the electrode voltages to the cathode-ray tube and also houses the heart rate circuit and a time-base which deflects the spot on the cardioscope screen. It would originally have been housed in a wooden box.
Black-painted top plate set on grey-painted metal frame which supports the electrical components. Various condensors, electromagnets and wires housed in the frame. Five-wire cable with socket for attachment to cardioscope. Two plastic switches on top plate, one for velocity (i.e. time base) which can be set to ‘F’ and ‘S’, one for the mains (on/off). Also a recording light under glass cover.
White metal handles for lifting instrument out of box.
Condition fair
References
Events
Description
An Electrocardiograph is a medical instrument that detects, displays, and records the electrical activity of the heart over a period of time, normally using electrodes attached to the surface of the skin. Its main use is to measure the rhythm of heart contractions and the relative strength of different parts of the heart muscle.
This is a control unit for an electrocardioscope. This part supplies the electrode voltages to the cathode-ray tube and also houses the heart rate circuit and a time-base which deflects the spot on the cardioscope screen. It would originally have been housed in a wooden box.
