Description
An electrocardiograph is a medical instrument that records the electrical activity of the heart. Physiologists discovered the electrical wave that accompanies the human heart beat at the end of the 19th Century and Dr Willem Einthoven designed an electrocardiograph using a string galvanometer to practically and precisely record it in 1903. It would eventually revolutionise the study of the heart and massively improve the treatment of heart disease. However, the original design was large and awkward - filling a room, weighing over 650lbs, and requiring patients to immerse their limbs in saltwater baths to transmit the heart's electrical current.

Dr Einthoven approached Cambridge Scientific Instrument Company to manufacture a marketable electrocardiograph and the Company proceeded with the redesign of the instrument. It completed its first full electrocardiograph in 1908. The Company continued to improve the electrocardiograph and make it smaller, but its design remained fundamentally unchanged for decades.

This is a control panel for a large table electrocardiograph, which was large and immobile and inconveniently, required patients to be brought to the machine.
26/03/2020
Created by: Morgan Bell on 26/03/2020

Description
An Electrocardiograph is a medical instrument that detects, displays, and records the electrical activity of the heart over a period of time, normally using electrodes attached to the surface of the skin. Its main use is to measure the rhythm of heart contractions and the relative strength of different parts of the heart muscle.

This is a control panel for a large table electrocardiograph.
