Accession No
0101
Brief Description
clinometer, rule form, by Troughton and Simms, English, 1870 (c)
Origin
London; England
Maker
Troughton and Simms
Class
surveying
Earliest Date
1870
Latest Date
1870
Inscription Date
Material
wood (boxwood); metal (brass)
Dimensions
length 155mm; breadth 52mm; thickness 11mm
Special Collection
Robert Whipple collection
Provenance
Purchased by Robert Stewart Whipple from J. Whitaker, Cambridge, on 24/05/1923.
Inscription
‘TROUGHTON & SIMMS LONDON’
Description Notes
Boxwood edged with brass. Hinged; graduated on inside 1-12” to 1/10”. Brass semi-circle set into inside graduated 90-0-90˚ to 1˚ with brass indicator arm. Outside with centigrade scale 0-54˚; Fahrenheit 20-130˚ Reaumer 0-43. Also table of degrees of slope.
References
Events
Description
Stanley described this type of clinometer as “much used by civil engineers as a working tool.” It could either be placed directly on a slope, such as a railway embankment, when the bubble would be centred, or rested on a flat surface in which case the distant object would be viewed through the sights.
