Accession No

5243

Brief Description

Priestley-Smith perimeter, by the Surgical Manufacturing Company, English, 1/2 20th Century

Origin

England; London; Mortimer Street

Maker

The Surgical Manufacturing Company Ltd.

Class

medical

Earliest Date

1900

Latest Date

1940

Inscription Date

Material

metal (brass, oxidized brass, white metal); wood (mahogany and one other); plastic; paper

Dimensions

box breadth 547mm; height 520mm; depth 226mm

Special Collection

Provenance

Transferred from Department of Physiology, University of Cambridge, on 23/01/1997.

Inscription

‘THE
SURGICAL MANUFACTURING Co.Ltd.
83 & 85, MORTIMER ST.
LONDON W.1.
MAKERS OF MODERN HOSPITAL EQUIPMENT.’ (on plaque attached to base)

Description Notes

Rectangular mahogany base with drawer set into it; drawer contains 6 black plastic squares with pieces of coloured card stuck to both sides - one side has small piece, the other has a larger piece - in blue, orange, red (2 types), yellow and green; also 2 drawing pins, a bulldog clip, and a metal rod. Two black-painted white metal standards mounted on base. On one standard is set a brass arc divided 0 - 90˚, numbered by 10˚, subdivided to 5˚. This arc rotates with a mahogany wheel, which carries a iron counterweight (to balance the arc). The wheel also has a central brass disc and 3 guides for holding a chart (the wheel is heavily pitted, where pins have pin used to hold charts in place). A metal arm from the standard supports, in the middle of the disc, a metal scale divided 0 - 90 numbered by 10. The arc can be fixed in position, using a knurled brass screw. The other standard carries a waved black metal plate (for resting the patient’s chin) which can be adjusted vertically by means of a knurled brass clamping screw. In front of this is a vertical black-painted brass rod, with a white-painted tip.
Wooden box with brass hinges and lock, steel key.

Incomplete (?)
