Accession No

5748

Brief Description

Van de Graaf generator, by Griffin & George Ltd., English, 1970-1999 (c)

Origin

England; London

Maker

Griffin and George Ltd.

Class

physics

Earliest Date

1970

Latest Date

1999

Inscription Date

Material

plastic (perspex, other, synthetic rubber); metal (aluminium, other)

Dimensions

diameter of base 250mm; height 495mm

Special Collection

Provenance

Donated by Anglia Polytechnic University (now Anglia Ruskin University), Cambridge, on 16/09/1999.

Inscription

‘GRIFFIN & GEORGE LTD. LONDON
MADE IN GT. BRITAIN
VOLTS 200-50 WATTS
SERIAL NO. 667/79’ (label stuck on base)
‘DANGER
HIGH
VOLTAGE’ (label stuck on plastic cover)
‘1500
OLT TEST 44’ (on top of motor)
‘200/250V08AMP
50/60~8WATTS’ (on part of motor)
‘GARRARD’ (on motor)

Description Notes

Van de Graaf generator. Base is circular and made of white plastic, with a terminal on it. On it is a smaller circle of black plastic, from which two joined rectangles of perspex extend upwards. At the top of the perspex a metal disc is attached, with another on top of it. Bolted horizontally across from just below this disc is a roller. A similar roller is attached to a motor on the base. Around the two rollers is a synthetic rubber belt. A comb (?) is positioned near the upper roller. The upper roller is surrounded by a detachable aluminium spinning, which rests on the top-most metal disc. The base and motor are covered by a plastic cover, with a hole in the middle throught which the belt and perspex block go.
Lead and plug attached to motor.

Label on bottom, from ‘Electrical Appliance Testing Ltd’, for passing a safety test, dated 1-1999.

Condition: good; complete.
