Accession No

5904

Brief Description

artillery director, used by Brian Harland during the surveys of Svalbard between 1949 and 1993, by C. Baker, English, 1936 -1938

Origin

England; London

Maker

C. Baker

Class

earth sciences; military

Earliest Date

1936

Latest Date

1938

Inscription Date

1938

Material

metal (steel, brass, other); glass; leather

Dimensions

Instrument: height 108 mm; width 90 mm Box: height 140mm; width 108 mm; depth 90 mm

Special Collection

Brian Harland collection

Provenance

Donated on or before 30/04/2003.

Inscription

DIRECTOR No. 9 M.K.1.
C. BAKER LONDON
1938 No. 31

On box: DIRECTOR . NO9.MK1
C.BAKER
1936

Description Notes

Artillery director used for topographical triangulation on survey of Svalbard.

The instrument has a central screw foot and key for mounting on a tripod. Set on a circular screw turn base marked 0˚-180˚-0˚ around the edge to allow the unit to swivel on the horizontal plane. The unit itelf consists of a bubble level and telescopic sight which also tilts in the vertical plane via a screw thread.

The instrument comes in a stitched leather carry case.

Condition: good; complete.
