Accession No
2206
Brief Description
Verschoyle clinometer by Stanley, c.1920
Origin
London
Maker
Stanley
Class
surveying
Earliest Date
1920
Latest Date
1920
Inscription Date
Material
metal (brass, oxidised brass, steel); glass
Dimensions
length of arm 128mm; diameter of circle 71mm; overall height 50mm
Special Collection
Provenance
Transferred from Department of Geography, University of Cambridge, Cambridge, England, 05/1969.
Inscription
‘Stanley, London’ (arm)
‘VERSCHOYLE
CLINOMETER
PATENT’ (reverse of circle)
Description Notes
Brass circle with bubble level mounted inside, viewed via a reflecting prism on sighting arm, which revolves freely on circle. Pinhole/window (with wire crosshairs) sights. Scale on circle divided 0 - 180˚ - 0, numbered by 10˚, graduated to 1˚, read by Vernier arm to 10´. Folding supports below sights for resting instrument on inclined surface.
Condition good; complete.
References
Events
Description
Verschoyle clinometer
Designed by Mr W.D. Verschoyle, “a mining engineer of great experience”, this instrument measures inclination and azimuth angles. To measure an incline the object is sighted, the spirit level (mounted inside the circular box) is viewed through the prism, and the bubble centred by rotating the box. The inclination is then read on the graduated scale and the vernier scale.
11/08/2006
Created by: updated by Ruth Horry on 11/08/2006
FM:39613
