Accession No

3901

Brief Description

fork Level, 2/2 19th Century

Origin

Maker

Class

surveying

Earliest Date

1850

Latest Date

1900

Inscription Date

Material

metal; (brass, oxidised brass, white metal); glass; wood; cloth (felt); rope (string)

Dimensions

level length 275mm; breadth 125mm; height 145mm box length 335mm; breadth 183mm; height 168mm stand length 237mm; breadth 130mm; height 185mm

Special Collection

Provenance

Transferred from Department of Geography, University of Cambridge, Cambridge, England, 28/10/1992.

Inscription

Description Notes

Fork level consisting of oxidised brass telescope tube with screw-fit eyepiece and objective lens (latter with cover with swing aperture control). Bubble level attached to top. Focussing knob with knurled head on one side of tube. Vertical circular silvered degree scale divided 0 - 90˚ - 0 - 90˚ - 0, numbered by 10˚, graduated to 0.5˚. With two Verniers marked A and B with magnifying lenses set above them. Clamp and tangent screw for scale.
Telescope mounted on horizontal axis which rests in forks of oxidised brass stand. Stand consists of two A-frame pillars with bubble level on one at base. Stand fixed on white metal plate (later addition).
Six brass screws.
Fitted wooden case, felt-lined with brass handle, hinges and fasteners.

Condition good (blackening of the scale, box lid cracked); complete
